Technical Parameters
- XYZ Stroke: 400*250*350mm
- XYZ Rail:Hiwin X20 YZ25 guide rail
- XYZ Ball Screw : TBI XY2005 Z2505
- Worktable Size: 630*230mm
- Machine Dimension: 1.6*1.2*1.9m
- X/Y/Z Verticality:+/- 0.01mm/200mm
- Repeatability:0.01mm
- CNC Controller: KYCNC 1000MC
- Z axis Motor: 2kw Servo With brake
- XY axis motor: 750W Servo motor
- Spindle: Blet Drive BT30 8000rpm
- Spindle Motor:2.2KW 14N 8000RPM
- Tool Magazine:12pcs Tool Library
- Coolant:Water Pump
- Support Software:Powermill,UG etc
- Cutting Material:Brass, Steel,Aluminum
- Weight:1100kg/2425lbs
